GX Series | GX 1000 OSP

GX Series |  GX 1000 OSP

The GX 1000 OSP machine is unique to the Bridgeport family of mills as it incorporates the Okuma OSP P200 CNC control, encoders, motors, and drives. The GX 1000's popularity has risen over the years as a true workhorse in the industry, and with the addition of the OSP P200 control this machine can offer even more performance capabilities! The Bridgeport GX 1000 OSP was designed to ensure customers with years of accurate and reliable machining performance. A stiff and thermally stable spindle, rigid C-frame fixed column design, and fixed pre-tensioned double nut ball screws on all axes are just some of the standard design characteristics that our customers have grown accustomed to. Standard Control Features • Panel PC • Windows XP OS • 15” Color Touch-Screen LCD • Intel Pentium Processor • 40 GB Hard Disk (built-in) • 512 MB (DRAM) • Program Storage Capacity 2GB • Operation Buffer Capacity 2MB • 2 USB ports, 1 RS-232 port • 1-Ethernet 10Base/100Base TX

Click me

Quick Specs

Travels: X,Y,Z [in (mm)] 40.1 x 21.25 x 21.25 (1020 x 540 x 540)
Spindle Taper No. 40
Spindle HP  [HP (kW)] 27 (S3 25%), 20 (S3 60%), 15 (Cont.)
Spindle Speed [RPM] 10,000
Tool Changer 30 Tools
Control Type Okuma OSP-P200
Working Surface [in (mm)] 44.09 x 21.25 (1120 x 540)
Floor Space [in (mm)] 116.3 x 84.2 (2955 x 2137)
Approx Machine Weight [lbs (kg)] 12,980 (5900)

pdf-icon    Download Full Specifications
